Do not install the battery into the aircraft or remove the battery
from the aircraft when the battery power is turned on.
Otherwise, the poor contact of the battery interface during the
operation may cause the battery to short-circuit and burn the
aircraft. The battery must be installed or removed with the
battery power turned off.
Install the intelligent flight battery
into the battery compartment and
push it down until you hear a "click"
from the battery buckle, indicating
that it pops up and locks. Make
sure the battery is in place.
To remove the battery, press the
buckles on both sides of the
battery and pull it out of the battery
compartment.
Push
Press the
button
and pull
Using the Battery
Press and hold the power button, after the indicator light turns on to
the fourth, release the power button to check the current battery level.
Checking Battery Level
High
Low
Electricity
