3 Technical Information
3.1 Indication LED Patterns
LED
Pattern
Description
Sat.
Once every second
Accurate signal
Once every 0.4 seconds
No signal
GSM
Once every 4 seconds
Accurate GSM and GPRS signal
Once every second
Accurate GSM signal, no GPRS
Once every 0.2 seconds
No signal
Always on
Link with the server is open
Periph.
Always off
No devices connected
Once every 5 seconds
One device connected
Twice every 5 seconds
Two devices connected
Three times every 5 seconds
Three devices connected
All
Once every 5 seconds
Sleep/deep sleep mode
3.2 12 Pin Cable Pinout
Pin
Wire color
Description
+BAT 12/24V
Red
Power supply 12/24V
Chassis
Black
Ground connection
DIN1
Pink
Digital input 1
DIN2
Blue
Digital input 2
DIN3
White
Digital input 3
DIN4
Yellow
Digital input 4
AIN1
Grey
Analog input 1
AIN2
Green
Analog input 2
DOUT1
Purple
Digital output 1
DOUT2
Orange
Digital output 2
CAN2 L
Blue/Red
CAN Low
CAN2 H
White/Red
CAN High
