3.5.2 Electrical Specifications
FM-Pro4
FM-Pro4 3G
Power supply range
10 – 32 V DC
Power supply voltage
12/24 V DC
Maximum voltage
ratings
50 V @ 60 s
72 V @ 0.1 s
Maximum current
rating
250 mA @ 12 V DC
350 mA @ 12 V DC
Internal battery
LiPo 3.7 V 190 mAh
Protections
Battery and 1-Wire power line short circuit protection
Reverse polarity protection
Electrostatic discharge protection on USB and 1-Wire data line
Overcurrent protection on 1-Wire power line
ESD protection on SIM card slot (can be ordered)
Charging protection
3.5.3 Power Consumption @ 12 V DC
FM-Pro4
FM-Pro4 3G
Operating
Idle mode: 52.6 mA
Active mode: 78.5 mA
Sleep mode: 17.3 mA
Deep sleep mode: 6.0 mA
Idle mode: 67.5 mA
Active mode: 102.0 mA
Sleep mode: 24.2 mA
Deep sleep mode: 6.2 mA
Operating while
charging battery
Idle mode: 167.5 mA
Active mode: 176.0 mA
Sleep mode: 130.9 mA
Deep sleep mode: 119.3 mA
Idle mode: 172.4 mA
Active mode: 211.4 mA
Sleep mode: 127.7 mA
Deep sleep mode: 114.1 mA
3.5.4 Connectivity
FM-Pro4
FM-Pro4 3G
GSM
Modem: Quectel M95
Antenna: Internal (Quad-band)
Frequency band @ GSM:
850/900/1800/1900 MHz
Modem: Quectel UG96
Antenna: Internal (Quad-band)
Frequency band @ UMTS:
850/900/1800/1900/2100 MHz
Frequency band @ GSM:
850/900/1800/1900 MHz
GNSS (GPS, GLONASS)
module
Modem: U-blox EVA-M8M
Antenna: External
Positioning systems: GPS, GLONASS, Galileo
Augmentation systems: QZSS, SBAS (WAAS, GAGAN, EGNOS, MSAS)
Frequency: 1575.42 MHz (GPS, GALILEO); 1602 MHz (GLONASS)
Tracking sensitivity: -164 dBm
Reacquisition sensitivity: -160 dBm
Cold start duration: < 30 s
Aided start: 3 s
