RUPTELA FM-Pro4 - Physical Characteristics; 14 Pin Cable Pinout; Dimensions and Material; Technical Characteristics

15
3.3 14 Pin Cable Pinout
Pin
Wire color
Description
Chassis
Black
Ground connection
PortA-232 RX
Purple
RS232 RX
PortA-232 TX
Pink
RS232 TX
PortB-232 RX
Yellow
RS232 RX
PortB-232 TX
Orange
RS232 TX
1W. +5V
Red
1-Wire power
1W. Data
Green/Yellow
1-Wire data
CAN1 H
White
CAN High
CAN1 L
Blue
CAN Low
L-Line
Green
CAN L-Line
K-Line
Brown
CAN K-Line
Chassis
Black
Ground connection
PortC-485A
White/Red
RS485 line A
PortC-485B
Yellow/Brown
RS485 line B
3.4 Physical Characteristics
Dimensions
111 x 75 x 25 mm
Weight
134 ± 10 g
Housing material
Plastic
Connectors
12 Pin and 14 Pin, insulated
Configuration interface
Mini USB
Antenna
External
3.5 Technical Characteristics
3.5.1 Environmental Specifications
FM-Pro4
FM-Pro4 3G
Temperature
Operating: -35 to +70 °C
Storage: -40 to +70 °C
Battery charging: 0 to +45 °C
Battery discharging: -20 to +60 °C
Battery storage: -20 to +70 °C
Relative humidity
0% to 95% Non-condensing
