4.4 Cable Connection
4.4.1 12 and 14 Pin Cable Connection
Connect the 12 and 14 Pin cables to their respective ports on the device as shown in the image
below. The cables can be connected in only one way.
4.4.2 USB Cable Connection
Connect the USB cable to the mini USB port as shown in the image below. The cable can be
connected in only one way. Connect the other end to your computer.
The device can be configured when powered via USB, using an external power supply for
configuration is optional.
