WARNING
To avoid serious personal injury, do not attempt
to use this product until you read thoroughly and
understand completely the operator’s manual. If you
do not understand the warnings and instructions in the
operator’s manual, do not use this product. Call Ryobi
customer service for assistance.
WARNING
The operation of any power tool can result in foreign
objects being thrown into your eyes, which can result
in severe eye damage. Before beginning power tool
operation, always wear safety goggles or safety glasses
with side shields and, when needed, a full face shield.
We recommend Wide Vision Safety Mask for use
over eyeglasses or standard safety glasses with side
shields. Always use eye protection which is marked to
comply with EN 166.
WARNING
Long term inhalation of the engine's exhaust fumes,
chain oil mist and sawdust can result in serious
personal injury.
Save these instructions and pass them on if the saw is to
be used by another person.
SPECIFICATIONS
Model name RCS4640C RCS4845C
Description
51 cc 40 cm
(16'') CE saw
51 cc 45 cm
(18'') CE saw
Weight - No bar, chain,
fuel
5.3 kg
Fuel tank capacity 575 cm
3
Lubricant tank capacity 350 cm
3
Bar length 40 cm 45 cm
Usable cutting length 38.5 cm 43.5 cm
Chain pitch 8.26 mm (0.325 inch)
Chain gauge 1.27 mm (0.05 inch)
Chain type 0.325" low pro¿ le full complement
Drive sprocket 7 teeth x 0.325''
Engine displacement 51 cm
3
Maximum engine power
(ISO 7293)
2.0 kW
Recommended
maximum engine speed
with cutting attachment
11,500 r/min
Recommended engine
speed at idling
2,600-3,600 r/min
Speci¿ c fuel consumption
at maximum engine
power
490 g/kwh
Sound pressure level
(ISO 22868)
LpAav: 100dB(A), KpA=3 dB(A)
Sound power level (ISO
22868)
114 dB(A)
Vibration (ISO 22867): Carlton/Oregon
– Front handle 8.12 m/s
2
, K=1.5
– Rear handle 8.0 m/s
2
, K=1.5
Bar & Chain (Carlton guide bar only use with Carlton saw
chain, and Oregon guide bar only use with Oregon saw
chain)
Guide bar (no silkscreen)
– Carlton part number 16-10W-K1-HC 18-10W-K1-HC
– Part number 310603001 310604001
– Color Black Black
Chain
– Carlton part number K1L-BL-66E K1L-BL-72E
– Part number 901197002 901430001
Guide bar (no silkscreen)
– Oregon part number 160 PXB K041 180 PXB K041
– Part number 308111001 308108001
– Color Black Black
Chain
– Oregon part number 20BPX-66 20BPX-72
– Part number 900920003 900920004
DESCRIPTION
1. Front hand guard/Chain brake
2. Front handle
3. Engine cover
4. Primer bulb
5. Choke lever
6. Chain
7. Starter grip
8. Guide bar
9. Trigger release
10. Chain lubricant cap
11. Silencer
12. Carburettor adjustment
13. Rear handle
