Ryobi RM300E - Getting Started: Assembly Steps; Initial Safety and Component Connections

13
Getting Started
3
1
2
3
1 2
1
2
1
2
1
2
1
2
2
1
3
3
3 4 5
1
2
3
6 7 8
Wear full eye protection, non-slip
heavy-duty gloves, substantial
footwear, and long trousers at all times
while operating the product. Do not
operate the product when barefoot or
wearing open sandals.
Push the tabs on rear side of the cable cover, and remove the cover. Connect the
battery cables.
Route the safety interlock cable through
the hole on the cable cover. Install the
cable cover until it clicks in place.
Remove the bolt and nut secured on the
seat mounting brackets.
Install the seat, aligning the mounting
holes to the mounting bracket on the
mower. Secure the seat using the bolt
and nut on each side.
Connect the safety interlock system
cable to the seat cable.
Pull down the seat. On the front side of the mower, install
the upper steering shaft over the lower
shaft. Secure the shaft with a bolt and
nut.
