Ryobi RM300E - Replacing the Mower Batteries

29
Maintenance
REPLACING THE BATTERIES
1. Engage the parking brake, stop the
blades, turn off the product, and remove
the start key.
2. Set the seat to the rearmost position.
3. Lift the seat forwards.
4. Disconnect the seat cable and safety
interlock cable.
5. On each side of the seat, remove the
bolt and nut that secure the seat to the
mower. Remove the seat.
1
2
3
2
3
4
3
2
2
3
1
1
5
1
p.20
