900 Convertible Top Troubleshooting Guide
6.
Top
stops
l/2
way down when lowering the top
a.
Missing 2nd bow drive link or 2nd bow binding on fabric?
Perform Customer Satisfaction Campaign 428 if it has not been completed
This problem can occur if the 2nd bow does not flip back, causing it to contact
the front side rails. This can bend the balance link.
If slightly bent, it is OK
to straighten it in the car.
If balance links are severely bent, they are available
as spare parts:
LH 47 67 398, RH 74 97 506
balance link usually bends
here toward center of car
If the balance link is bent, also inspect the control arm on both sides for bend-
ing.
check for bending at this area
5
06/09/97
