PSI
04/97
-
0753
5.
Unplug
the luggage compartment lighting connectors and fold down the trim.
6.
Press the chafing guard in place on the antenna bracket as shown in Figure 14.A above.
7.
Wrap duct tape around the tube of the antenna mast to prevent the trunk light from
shorting
against
it.
8.
Do not refit the trim and scuff plate until repair steps
14,15
and 16 have been completed.
Change the Tonneau cover potentiometer.
Parts:
Potentiometer kit
45
58
771
Consists of:
0
Potentiometer
?? Bracket
?? Adapter
0
Screw (2)
Cable tie
79
71
880
Figure 15. Changing the Tonneau cover potentiometer
IMPORTANT
When this repair has been carried out, it will not be possible to operate the top by means of the ROOF switch
until the potentiometer resistance readings have been programmed into the ECM. See Step 17.
1.
The top should be fully raised, the first and 5th bows should be locked from the previous step.
