PSI
04/97
-
0753
1
See Customer Satisfaction Campaign 428, PSI
04/97-0754,
Step B. Replace pins, adjust
1
top stops per Service Manual
85
Cabriolet, page 130 and reprogram.
NOTE: On later cars the wiring has been routed behind the antenna bracket.
Fit a chafing guard on the antenna bracket to reduce the risk of damage to the wiring.
NOTE
Subjects
#14,15
and 16 should be done at the same time in the trunk.
Parts:
Chafing guard
82 78 558
Duct tape
Figure 14. Fitting guard to antenna bracket
1.
Operate the top using the “ROOF” switch until it is in the position shown above. The top
should
be
fully
raised, the first and 5th bows should be locked.
2.
Remove the scuff plate from the luggage compartment.
3.
Remove the clips securing the luggage compartment trim on the LH side.
4.
Detach the luggage compartment weatherseal on the LH side.
Page 15
of 24
To Next Page
