psr
04/97
-
0753
11.
Refit
the rear lamp cluster.
12.
Refit the luggage compartment trim.
13. Refit the luggage compartment weather-seal on the RH side.
14. Do not refit the trim and scuff plate until repair step 16 has been completed.
Check with Tech 2 or
ISAT
for the version of the TSAS ECM.
If it is a version lower than
0402, replace it. If it is a version 0402 or higher, proceed as follows.
Since the new ECM can generate an additional SID message, the
SID
and the owner’s manual should also be
Up-,
dated.
Parts:
TSAS ECM
Owner’s Manual Label
Tools:
m
ISAT
or Tech 2
46 10 812
04 08 948
IMPORTANT
When these steps have been taken, it will not be possible to operate the top mechanism by means of the ROOF
switch until the potentiometer resistance readings have been programmed into the new ECM.
NOTE: The new ECM will not allow the windows to be raised while operating the top (old ECM did allow
for
this).
Figure 17.
TSAS ECM and Owner’s Manual Label
Page 18 of 24
