Saab 900 Convertible - Removing Right-Hand Microswitch

PSI 04/97 - 0753
14. Remove the covering shell as indicated in Figure 11 .A.
15. Remove the screws securing the right-hand microswitch as indicated in Figure 11 .B.
16. Snip the cable tie holding the connector in position
17. Unplug the connector. See Figure 11 .C.
18. Remove and scrap the existing microswitch.
19. Cover open end of connector with a piece of tape to protect end of pins.
20. Fasten the wiring into place using a cable tie. See Figure 11 .D.
21. Refit the covering shell and tighten the bolts.
Figure 11. Removing right-hand microswitch
Page 12 of 24
