04/97-0753
Car’s rear wiring harness:
7.
Withdraw the green lead with female pin from position 3 in the male part of connector
HlO-15.
8.
Withdraw
the yellow/white lead with female pin from position 4 in the male part of
connector
H10-15.
9.
Cut Off the pins from both leads and strip them (leave wire as long as possible to avoid
strain on harness after
repair).
10. Place both leads together and crimp a new female sleeve, P/N 91 20 957 onto them.
11. Press the leads into position 10.
12. Plug in connector
Hl
O-l 5.
13. Fit the top storage bag in place and refit the Tonneau cover weatherseal.
NOTE
Make certain top storage bag and Tonneau cover weatherseal are refitted completely to allow for
full
dow-
nard movement of top on left side. Otherwise, top movement restriction will not allow proper programming
to take place.
9
cl
GY
6
‘I
I3
4
2
cl
6
7
cl
r
A
B
1
Tonneau cover and car wiring
f-l
fl
Tonneau cover wiring harness
harness before repair action
after repair action
rjf@-@-fJ
pb-+@j-
C
Car’s rear wiring harness after repair action
Figure 10. Modifying wiring
