5-12 Audio
Premium AM/FM/6-CD Audio System 3
33
3
The radio will operate only when the ignition switch is in the “ACC” or “ON” position.
¢ Radio operation
(1)
(8) (7) (6)
(2) (3) (4) (5)
500247
(1) FM button
(2) AM button
(3) Tone selection button
(4) Balance selection button
(5) SCAN button
(6) Tuning knob
(7) Preset buttons
(8) Power switch, Volume control, Bass/
Midrange/Treble control and Fader/
Balance control dial
q Power switch and volume/bass/tre-
ble/fader/balance control (PWR/
VOL)
The dial (8) is used for both power (ON/
OFF) and volume control. The radio is
turned ON and OFF by pushing the dial
and the volume is controlled by turning the
dial.
This dial is used for bass/midrange/treble
controls when the “TONE” button (3) is in
the depressed position. It is also used for
fader/balance controls when the “BAL”
button (4) is in the depressed position.
A1910BE-A-GSAAB.book Page 12 Tuesday, September 6, 2005 8:37 AM
