Maintenance and service 11-47
11
– CONTINUED –
1. Remove the air intake duct mounting
bolt, then remove the air intake duct.
2. Remove the bulb cover by turning it
counterclockwise.
3. Push the retainer spring in the direction
of the arrow to remove it from the hook.
4. Pull the bulb out of the electrical con-
nector. Replace the bulb with a new one.
5. Set the retainer spring securely.
6. Reconnect the electrical connector.
7. Install the bulb cover.
q Left-hand low beam light bulb
q High beam light bulbs
0
1. Remove the bulb from the headlight
assembly by turning it counterclockwise.
B00485
B00486
700092
B00488
Replacement of the left-hand low
beam light bulb requires removal of
the battery and is thus dangerous. It
must be performed by a Saab deal-
er.
B00489
