Sabre 1336HR - COMMANDS AND CONTROL INSTRUMENTS

4. COMMANDS AND CONTROL INSTRUMENTS
1. Steering wheel
Turns the front wheels.
2. Accelerator lever
Regulates the engine's r.p.m. The positions are indicated on a plate showing the
following symbols:
Position «CHOKE» for starting up.
Position «SLOW» for minimun engine speed
Position «FAST» for maximum engine speed
eng 13COMMANDS AND CONTROL INSTRUMENTS
N
1
2
5
10
8 7
6
12
9
B
A
4
A
B
3
R
F
11
A
B
B
A
13
