2.4 Technical Specifications
Size (w x h x d) 334 x 571 x 452 mm
25 capsules approx. 21 kg
Machine housing material Metal - Thermoplastic material
Power Rating See the data plate
Supply Voltage See the data plate
Power cord length approx. 1,200 mm
Capacity
Water tank
4.0 litres
Coffee grounds
drawer
40 grounds
Control panel Front panel
A-weighted sound pressure level less than 70 dB
Pump pressure Max. 1.5 MPa (15.0 bar)
Water connections (for water NW version only)
Maximum
pressure
0.8 MPA (8 bar)
Minimum
pressure
0.15 MPA (1.5 bar)
Operating conditions
Minimum temperature:
above 2°C
Maximum temperature:
less than 32°C
Maximum humidity:
less than 80%
Safety devices Boiler pressure safety valve
Safety thermostat
Subject to engineering and manufacturing changes due to technological improvements.
