US English
5
22
Remove the screw shown in the picture.
Remove the coffee dispensing spout.
Remove the front cover by pushing on its sides to
disengage the fixing elements.
Remove the lid on the left-hand side by loosening the 2
screws.
Install the spacer on the left-hand side of the machine and
fix it using the 4 screws supplied.
The machine has two
different connectors, a
square-shaped one for the
"Apollo" payment system
and a rectangular one to
connect the coiner.
To Next Page
