4.6. The SAVE and CANCEL buttons
For each channel there are two independent presets: one for activation and one for conditioning.
Presets can be saved to permanent memory or changes can be cancelled restoring previous
settings.
SAVE
CANCEL
4.7. The START/STOP buttons
START / STOP buttons are the first indicator of the status of the output.
If the output cable is well connected, START button is enabled to start supplying the power.
During the supply, STOP button is enabled to stop supplying the power.
If there are or there have been some problems that the user has not acknowledged yet, the
button is disabled.
