2.7. NEG POWER SMALL: the front panel of the unit
14. touch screen display
2.8. NEG POWER SMALL: the rear panel of the unit
15. instrument MAIN INPUT IEC 16 A: plug for mains power supply
16. ON/OFF instrument power switch
17. IN/OUT interface connector with INTERLOCKS
18. LAN connector: RJ45 connector for Ethernet
19. Fan for power modules 1 and 2
20. OUTPUT 1 pump connector
21. OUTPUT 2 pump connector
14
16
15
18
17
21
20
