SAES NEG POWER - NEG Pump Summary Table

M.HIST.0101.23 R2 Page 25 of 36 January, 26
th
2021
7. Summary Table of the NEG Pumps controlled by the NEG POWER
GP PUMPS
Model Pump Notes
Activation
Voltage (nude)
[V]
A
ctivation
Current (nude)
[A]
A
ctivation
Power (nude)
[W]
Temperature
[°C ]
GP 50-2F st 707 25 2.8 75 (450°C) NO TCK
GP 50-2F st 101 49 4.6 225 (700°C) NO TCK
GP 100 st 707 - MK5 41 3.4 138 450
GP 100 st 101 - MK4 81 5.2 420 700
GP 200 st 707 - MK5 52 3.8 200 450
GP 200 st 707 - MK4 25 7.0 175 450
GP 500 st 707 - MK5 61 9.4 580 450
GP 500 st 707 - MK4 46 9.9 455 450
GP 500 - SP8 st 707 110 4.5 500 500
GP 500-2X st 101 - MK5 70 10 700 700
CAPACITORR PUMPS
Model Pump Notes
Activation
Voltage (nude)
[V]
A
ctivation
Current (nude)
[A]
A
ctivation
Power (nude)
[W]
Temperature
[°C ]
CT D400-2 st 172 16 5.0 90 (450°C) NO TCK
CT D1000 st 172 43 4.3 190 550
CT D2000 st 172 110 4.6 500 450
CT D3500 st 172 92 3.9 360 550
NEXTORR PUMPS
Model Pump Notes
Activation
Voltage (nude)
[V]
A
ctivation
Current (nude)
[A]
A
ctivation
Power (nude)
[W]
Temperature
[°C ]
NXT 100-5 st 172 9 5.0 45 (450°C) NO TCK
NXT 200-5 st 172 12.5 4.8 60 (450°C) NO TCK
NXT 300-5 st 172 20 4.6 92 550
NXT 500-5 st 172 24 4.8 120 550
NXT 1000-10 st 172 58 4.5 260 550
NXT 2000-10 st 172 66 4.2 280 550
