8. PRODUCT CONFIGURATIONS AND ACCESSORIES
Configurations and accessories are given in the following section:
8.1. NEG POWER configurations and accessories:
Product description Code Note
NEG POWER C1 3B0501 Controller for NEG Pumps ( 1 output )
NEG POWER C2 3B0502 Controller for NEG Pumps ( 2 outputs )
NEG POWER C3 3B0503 Controller for NEG Pumps ( 3 outputs )
NEG POWER C4 3B0504 Controller for NEG Pumps ( 4 outputs )
Additional power module Power module to upgrade NEG POWER
Cable Mains input 2mt 3B0336 Main cable with IEC 16 A plug length 2 m
Cable Mains input 10mt 3B0352 Main cable with IEC 16 A plug length 10 m
Interlock connector DB25 connector with interlock connections
NEG POWER LP C1 3B0521 Controller for NEG Pumps ( 1 output low power )
NEG POWER LP C2 3B0522 Controller for NEG Pumps ( 2 outputs low power)
NEG POWER LP C3 3B0523 Controller for NEG Pumps ( 3 outputs low power)
NEG POWER LP C4 3B0524 Controller for NEG Pumps ( 4 outputs low power)
Additional low power module Power module to upgrade NEG POWER LP
NEG POWER hybrid S1L1 C2 3B0525 ( 1 output standard power and 1 output low power )
NEG POWER hybrid S1L2 C3 3B0526 ( 1 output standard power and 2 outputs low power )
NEG POWER hybrid S1L3 C4 3B0527 ( 1 output standard power and 3 outputs low power )
NEG POWER hybrid S2L1 C3 3B0528 ( 2 outputs standard power and 1 output low power )
NEG POWER hybrid S3L1 C4 3B0529 ( 3 outputs standard power and 1 output low power )
NEG POWER hybrid S2L2 C4 3B0530 ( 2 outputs standard power and 2 outputs low power )
NEG POWER SMALL LP C1 3B0531 Controller ½ rack ( 1 output low power )
NEG POWER SMALL LP C2 3B0532 Controller ½ rack ( 2 outputs low power )
NEG POWER SMALL S1L1 C2 3B0533 Controller ½ rack ( 1 low power 1 standard power)
NEG POWER SMALL C1 3B0534 Controller ½ rack ( 1 output standard power )
NEG POWER SMALL C2 3B0535 Controller ½ rack ( 2 outputs standard power )
