6. Electrical Specifications
Input:
Maximum Power 3.5 kW
Supply voltage 100-240 V~, +/-10%
Frequency 50/60 Hz +/- 10%
Input Current 20 A max
Mains cord connector IEC Type 16A 250V
Over-Voltage category II
Pollution degree 2
Isolation type class I
Altitude max up to 2000 m
Operating Temperature 0°C to 40°C
Relative Humidity 80%
Noise at 1 mt < 40 dBA
Standard modules
Output1-4 at 110 V:
Output power 700 W + overload
Output Voltage 10-110 V
Overload 110% for one minute
Supply Current 10 A (at 70 V )
Low power modules
Output1-4 at 30 V:
Output power 150 W + overload
Output Voltage 0-30 V
Overload 110% for one minute
Supply Current 5 A
NEG POWER models Maximum Rated Current
3B0501-3B0502-3B0503-3B0504 20 A
3B0521-3B0522-3B0523-3B0524 10 A
3B0525-3B0526-3B0527 20 A
3B0528-3B0529-3B0530 20 A
3B0531-3B0532 10 A
3B0533-3B0534-3B0535 16 A
