Functional unit workshop service VHF 5000 System
3-40
0608
Reference Operation/Test Test Criteria Comments/instructions
TIC-01 Power up radio
Pass:
Activity observed Digital output from baseband board (Pin 16)
Fail:
Otherwise Check signal is toggling when
activating/deactivating PTT.
Pass:
Activity observed Digital output from baseband board (Pin 15)
Fail:
Otherwise Check signal is toggling when
activating/deactivating PTT.
Pass: Signals high when
required.
Digital outputs from RF board.
Fail: Otherwise Pin 12 – RX lock detect shall be high
while receiving (measured 1 second after
PTT is released).
Pin 14 – TX lock detect shall be high
while receiving (measured 1 second after
PTT is pressed).
Pin 13 – DSC lock detect shall always
be high (measured 1 second after power-
)
Any system failure reporting wrong
frequencies in the display during normal
operations, are related to these signals.
Pass:
High on active PTT.
Fail:
Otherwise
Pass:
High on active PTT.
Fail:
Otherwise
Pass:
High on active PTT.
Fail:
Otherwise
Pass:
Activation observed. Digital output from baseband board Pin 9).
Fail:
Otherwise This signal is toggled by pushing the 1W
button on the transceiver front.
Pass:
High on active PTT.
Fail:
Otherwise
Pass:
Follow duplex channel
selections (high on duplex
channel).
Fail:
Otherwise
TIC-09 Power Valid Digital output from RF board (pin 11). Shall
be high during transmission (measured 1
second after PTT is activated).
TIC-10 Duplex (RT5020 duplex
radio only)
Digital output from baseband board. The
duplex signal shall toggle if a channel shift
from a duplex to a simplex channel is
performed (or vice versa).
TIC-07 PA Key Digital output from baseband board Pin 7).
TIC-08 Power 1W/25W
Digital output from baseband board (Pin 8).
TIC-06 High Tension Digital output from baseband board Pin 6).
TIC-04 Lock Detects
TIC-05 PTT
TIC-02 SPI clock
TIC-03 SPI Data
Tabel 19 (TIC) - Transceiver interconnection control signal verification tasks.
Control signals shall be verified before any AF signal path is checked (Transceiver interconnection control signal
flow). If any of the control signals are failing it makes no sense to continue the following check flow (Transceiver
interconnection AF flow).
