VHF 5000 System Functional unit description
1-7
Handset Unit
40340
Cable f. Handset
Microphone
PTT
Hook off
Earpiece
The default handset is of a non intelligent type consisting of an electret microphone and an earpiece and a PTT
key. All built in a sturdy housing. In the housing is also placed a reed switch and together with a strong magnet
in the cradle, it forms a hook-off function.
The handset used together with the remote control unit CU5000 is waterproof.
1.3 The CU5000 remote control unit
Should also include short description of the handset used.
40341
Sparc-II
to External
Laudspeaker
DISPLAY
CPU
KEYBOARD
RS
485
Att.2
Att.1
Audio PA
Int.
Loudspeaker
Handset
earpiece
Hook off
PTT
Handset
Microphone
0608
