Sailor RT5022 Workshop Manual

VHF 5000 System Functional unit workshop service
3-51
Reference Operation/Test Test Criteria Comments/instructions
LAN-01 Power up radio Wait for approximately 20 seconds in an
installation before any checks are
performed.
Pass:
The IP address on the
LAN box can be read out on
the transceiver display.
Fail:
Not connected or IP
address 0.0.0.0 is reported.
LAN-03 Connect PC Connect a service PC and browse for the IP
address displayed in LAN-02.
Pass:
Index page is
displayed correct.
Fail:
Otherwise
Verify the correct cable is used to connect
the service PC.
• Crossed cable in connections without
Ethernet switch
• Otherwise a straight cable is used.
Pass:
VHF radio software
versions are displayed on the
main service page.
Fail:
Otherwise.
Pass1:
The printer server is
identified on the radio.
1)
The printer server is reported in the self
-
test accessory menu
(5.6.4)
.
Pass2:
A test page can be
printed.
2)
A test page is printed from the self-test
menu
(5.7)
LAN-06 Verify VHF file system
LAN-07 Verify printer function
Verified under the self-test menu
5.6.3.
LAN-04 Verify LAN HTML service
pages
LAN-02 Address of the LAN box
LAN-05 Check cabling
Tabel 22 (LAN) - Lan box verification
3.5.5 Common user faults
Common problems using the SB5006/LB5007 units have been listed in the Trouble shooting section of the
SB5006 manual (also Part 5 in this manual).
