In case that the belt is stopped during the calibration procedure, the following screen will be
displayed.
Press “ SURE SPAN ” to below display:
When the automatic calibration is finished, the screen returns to the first menu of Auto Span.
P ress “ Manual Cal. ” to enter “ Manual cal ” menu.
“ Manual Cal ” allows input and change span value via key board.
2010-11-09 12:00:00 Scale#1
8 000000 t
888 t/h
1m/s
Auto span in progress ！
Belt stops! [10]
BGIN EXIT
CAL CAL
2010-11-09 12:00:00 Scale#1
8 000000 t
Old Span
：
[ 888 ]
New Span
：
Manual span mode. ！
Input span ：
BGIN EXIT ENTR ENTR
CAL CAL SPAN
2010-11-09 12:00:00 Scale#1
55. 00 t
Old Span ： [3751850 ]
New Span ： [ 3751850 ]
Auto span complete
！
Span err ： [0% ]
BGIN EXIT
CAL CAL
