B efore span calibration, standard weights must be loaded: in “ Cal. data setup 1 ” under
system main menu “ 3. system setup ” , modify calibration method, select “ weight cal ” in
simulated calibration, and enter weights weight in “ weights weight ” as shown in below
screen:
For deails refer to 3.3.5.
There are two spanning modes available: automatic spanning and manual spanning.
Press the “ AUTO SPAN ” soft key under 3.2.2.6 menu for the following screen:
2010-11-09 12:00:00 Scale#1
8 000000 t
888 t/h
1m/s
Auto span mode ！
AUTO EXIT MANL
CAL CAL CAL
2010-11-09 12:00:00 Scale#1
8 000000 t
888 t/h
1m/s
Auto span in progress ！
[ 100 ]
BGIN EXIT
CAL CAL
2010-11-09 12:00:00 Scale#1
CALIBRATION DATA 1
Simulated ： ELECTRIC
Resistor ： [ 165000Ohms ]
Weights ： [ 100kg ]
Chain ： [ 100kg/m ]
Press ↑↓ key, then press ENT!
MAIN SLCT ENTR PAGE PAGE
MENU DOWN UP
