6101
6101
6101
6101 Belt
Belt
Belt
Belt Scale
Scale
Scale
Scale Integrator
Integrator
Integrator
Integrator Operating
Operating
Operating
Operating and
and
and
and Service
Service
Service
Service Manual
Manual
Manual
Manual
73
B elt clip detector can decrease flow rate error caused by metal plate at the belt coupler.
N ormally clip detector is a proximity switch. W hen it detects clip in manual method, clip
detector keeps flow rate constant, and stable in condition of desired belt length without
influence on totalizing . In automatic method, integrator automatically checks tare weight
change and makes compensation accordingly. Auto track must be effecitive, cause auto zero
track store tare weight in memory for tare weight compensation of fluctuation point by point.
3
3
3
3 .
.
.
. 2.6
2.6
2.6
2.6 Communication
Communication
Communication
Communication Menu
Menu
Menu
Menu
Pressing “ 5 ” from Main Menu enters the first page of the Communication Menu.
Press ENTR soft key to view the optional settings and press SURE soft key until the desired
value is displayed.
Setup range see below table:
Description Range
Function NO DEFINE, MODBUS , PRINT
Baud Rate 4800 、 9600 、 19200 、 38400 、 115200
Word Length 8 BIT, 7 BIT
Stop Bit 1 BIT, 2 BIT
2006-3-21 12:00:00 Scale#1
COMMPORT 1 SETUP
Function ： [ MODBUS ]
Baud Rate ： [ 115200 ]
Word Length
：
[ 8BIT ]
Stop Bit ： [ 1BIT ]
Press ↑↓ key, then press ENT!
MAIN PAGE
MENU DOWN
2006-3-21 12:00:00 Scale#1
1 ． INITIAL SETUP
2 ． CALIBRATION
3 ． SYSTEM
DATA
4 ． I/O DEFINITION
5 ． COMMUNICATION
Press a numeric key to select.
PREV PAGE
RUN DOWN
To Next Page
