Pressing “ 7 ” from the second page of Main Menu enters the first page of the Loadout Setup
Menu.
Press Up/Down scroll keys to move the cursor to other variables.
Parameter range:
NAME RANGE Remark
Weight 0 1000000 If applied
Correct AUTO MANUAL If applied
Pre Value 0 1000000
Pre Range 0 1000000 If applied
When integrator totalizing is up to pre setting, integrator sends loading completed signal,
if
the material reached subordinate actually doesn ’ t conform to the actual material, change pre
value. E xample, if material of 100t is expected to be loaded in one train wagon, change the
pre value into 100t, if the actual material reached is 90t, then change the pre value into 110t.
2006-3-21 12:00:00 Scale#1
LOADOUT SETUP 1
Weight ： [ 50 t ]
Correct ： [ AUTO ]
Pre Value
：
[ 5 t]
Pre Range ： [ 10% ]
Press ↑↓ key, then press ENT!
MAIN PAGE PAGE
MENU DOWN UP
2006-3-21 12:00:00 Scale#1
6 ． ALARM SETUP
7 ． LOADOUT
LOADOUT
LOADOUT
LOADOUT SETUP
SETUP
SETUP
SETUP
8 ． PASSWORD SETUP
9 ． DIAGNOSTICS
10 ． STA TISTICS
Press a numeric key to select ！
PREV PAGE
RUN UP
To Next Page
