91
Yes
No
Normal
yes
Figure 4- 3 Troubleshooting Load Cell Input
Start
Check load cell input, Power on the
6101 and enter Diagnostics menu
The load indication is between 1 and
16777216, and increases as the
actual load increases
No load cell input
Check load cell and wire connection
Repair and replace
Load cell input is
normal
End
The excitation voltage on the load
cell should be DC 9.5 to 10.5V
The voltage between signal leads of
the load cell should be lower than 30mV
Bad excitation input
on the CPU
Damaged load cell
Bad load cell input on
the CPU board
