Figure 1
3.2 Recommend Tools
● Precision screwdriver (for small Phillips screws)
● Compass or GPS (for wind direction calibration)
● Adjustable Wrench
3.3 Sensor Assembly Set Up
The following illustration shows the full segment for Thermo-Hygrometer，WIND,RAIN
and UV INDEX sensor .(Display purposes only), as shown in Figure 2.
Figure 2
3.3.1 Insert batteries into the transmitter. Locate the battery door on the transmitter,
push and open the battery compartment, as show in Figure 3.
