SAJ H1 Series User Manual

H1 Series
- 21 -
5.3 AC Grid Wire and Backup Output Connection
Caution：For safety operation and regulation compliance, it is requested to install a
breaker (63A) between grid and inverter.
Cable Cross-sectional area（mm²）
External diameter（mm）
Range
Recommend
Range
Recommend
2.5~6.0
4.0
8~14
14
Table 5.2 Recommended Specifications of AC Cables
If the grid-connection distance is too far, please amplify diameter selection of the AC
cable as per the actual condition.
5.3.1 Open the waterproof cover, feed the AC cable through the AC
waterproof hole.
Figure 5.2 Thread the cables

SAJ H1 Series Specifications

General

Type	Hybrid Inverter
MPPT	Dual MPPT
Battery Compatibility	Lithium
Output Voltage Range	220/230/240V
Frequency Range	50Hz/60Hz
Communication	Wi-Fi
Protection	Overvoltage
Operating Temperature Range	-25°C to +60°C
Storage Temperature Range	-40°C to +70°C
Humidity Range	0% to 100%
Altitude	4000m
