H1 Series
- 16 -
50CM
30CM
50CM
30CM
30CM
Figure 4.2 Minimum Clearance
4.4 Mounting Procedure
4.4.1 Mark the Positions of the Drill Holes of the Rear Panel
The mounting position should be marked as shown in Figure 4.3.
Figure 4.3 Dimensions of rear panel of H1 inverter
