• Do not install the device at daily working or living arears, including but not limited to the following areas:
bedroom, lounge, living room, study, toilet, bathroom, theater and attic.
• When installing the device at the garage, please keep it away from drive way.
• Keep the device from water sources such as taps, sewer pipes and sprinklers to prevent water seepage.
• The product is to be installed in a high traffic area where the fault is likely to be seen.
Note: When installing outdoors, the height of the device from the ground should be considered to prevent the
device from soaking in water. The specific height is determined by the site environment.
4.3 Mounting Procedure
4.3.1 Installation Tools
Installation tools include but are not limited to the following recommended ones. Please use other auxiliary
tools on site if necessary.
4.3.2 Mounting Procedures
1. Mark the Positions of the Drill Holes on the Rear Panel
The mounting position should be marked as shown in the following figure.
Figure 4.4
Mark positions
2. Drill Holes and Place the Expansion Tubes
Drill 4 holes in the wall (in conformity with the position marked in Figure 4.4), and then place expansion tubes
in the holes using a rubber mallet.
