Salus RT310 - Frost Protection Mode; Sleep Mode Operation

Technical info
Product Specication
Model: RT310
Type: Wired Heating Thermostat
Temperature
Scale: °C
Range: 5.0°C - 35.0°C
Resolution: 0.1/0.5°C and 0.5°C default
Temperature Measurement
Accuracy:
Maximum +/-0.25°C at 20°C
Display Range: 5.0°C - 35.0°C
Display Resolution: 0.1/0.5°C and 0.5°C default
Frost Protection
Setting: 5 ºC
Setpoint Temperature Range: 5 ºC to 17 ºC
Thermostat
Power Source: 2xAA Alkaline batteries
Switch Rating
Switching Voltage: 0-230V
Switching Current: 3A resistance 1A inductance
Protection Rating: IP 30
Environment
Operating Temperature/
Humidity:
0°C ~ 50°C, 10% – 90% non-condensing
Storage Temperature/
Humidity
-20°C~- 60°C, 10% – 90% non-condensing
Factory reset
Press the Reset button once. You can use a paper clip. Your
thermostat will be reset and will start up automatically.
TESTING/PAIRING
12 RT310 Installation Manual
