RT310i Installation Manual 09
2.3.4.5 Pairing with the thermostat procedure
If you want to re-pair devices with
each other, make sure that the re-
ceiver is disconnected from the po-
wer supply and the switches on it
are in the AUTO and ON positions.
Then connect the receiver to the
power supply and wait for the red
diode to glow continuously.
Move the top switch to the OFF
position and back to the ON
position with a quick motion.
The red LED will start blinking
to confirm that the receiver
has entered the pairing mode.
1 2 3
When the red diode on the re-
ceiver lights up continuously,
the devices have been paired
on a new frequency.
WARNING! If the red diode on the receiver has not stopped blinking after 10 minutes, repeat the
pairing process taking into account the distance between devices, obstacles and interference.
TEST / PAIRING
TEST / PAIRING
TEST / PAIRING
TEST / PAIRING
NOTE: RT310i THERMOSTAT IS ALREADY PAIRED WITH THE RECEIVER!
Pairing process can take up to
9 minutes.
Thermostat went back to the
main display.
Press and hold TEST / PAIRING
button for 3 seconds.
Once devices are successfully
paired, LED on the receiver will
go solid red. Press and hold TEST
/ PAIRING button for 3 seconds to
end the pairing process.
3 sec
3 sec
4
7
5
8
6
