Salus RT310RF - Connection description

Technical info
Product Specication
Model: RT310RF
Type: Wireless Heating Thermostat
Frequency: 868MHz
Temperature
Scale: °C
Range: 5.0°C - 35.0°C
Resolution: 0.1/0.5°C and 0.5°C default
Temperature Measurement
Accuracy:
Maximum +/-0.25°C at 20°C
Display Range: 5.0°C - 35.0°C
Display Resolution: 0.1/0.5°C and 0.5°C default
Frost Protection
Setting: 5 ºC
Setpoint Temperature Range: 5 ºC to 17 ºC
Thermostat
Power Source: 2 AA-sized Alkaline Batteries for a minimum of 12 months operation.
Receiver
Power Source: 230Vac 50Hz
Switch Rating
Switching Voltage: 230V/50Hz
Switching Current: 16A resistance 8A inductance
Protection Rating: IP 30
Environment
Operating Temperature/
Humidity:
0°C ~ 50°C, 10% – 90% non-condensing
Storage Temperature/
Humidity:
-20°C~- 60°C, 10% – 90% non-condensing
Factory reset
Remove the batteries without pressing any button. Wait 2 minutes and insert the batteries again.
RT310RF Installation Manual 13
