USER CONTROLS
Integral RF Boiler Control
A – LED This LED will be on when the
thermostat is demanding heat.
B – Mode Switch ON – Boiler will be on
continuous AUTO – will follow time and
temperature program in the transmitter
OFF – Boiler is off
C – SYNC Button - This is used only for
pairing the RF communications.
SETTING UP RF COMMUNICATION WITH
YOUR THERMOSTAT
If you find that your thermostat will not communicate with
integral boiler control please follow the steps below:
1. Ensure the switch on the
RF integral boiler module
is in the AUTO
2. Gently press and hold the SYNC
button with a blunt object. After
3 seconds the Boiler Control LED
will flash once every second to
indicate it is ready to pair and
ready to receive a signal from
the thermostat*.
* For full instructions on thermostat pairing see:
RT505TX Manual - Page 13 ST325TX Manual - Page 15
RT305TX Manual - Page 9 ST625TX Manual - Page 11
SYNC Button
RXWBC605 INSTRUCTION MANUAL
23
