11.4. APPLY ULTRASOUND
COUPLING PATCH TO TREATMENT
LOCATION
A. Hold the applicator so the bottom of the
Patch faces up. Remove the circular foil
seal, revealing the gel.
B. Remove the paper liner, revealing the
Patch adhesive (Figure 10A).
i. Add more sam Coupling Media
as needed.
C. Turn the Patch over and adhere the Patch
to the desired treatment location (Figure
10B).
i. The sam Coupling Media must be in
direct contact with the skin.
If using dual applicators, repeat these steps to
adhere the second Patch and applicator to the
second treatment site.
Note: When applying Patches, both sides of
the ultrasound coupling media should be
uncovered. One side should be in contact
with the skin. The other side should be in
contact with the face of the applicator.
figure 10A: Removing Paper Liner
figure 10B: Adhere Patch to Site
