APPENDIX A
SECTION 4 | Parameter Setup
NOTES FOR FIG 3.2:
1. • The3-digitNo.XXXin“RC-XXX”indicatestheFirmwareRevisionNo.fortheRemote
Control EVO-RC
 • The4-digitNo.XX.XinEVO-VX.XXdenotestheFirmwareRevisionNo.fortheEVO
 • The4-digitNo.XXXXinEVO-XXXXdenotestheModelNo.ofEVOi.e.2212/2224/
3012 / 4024
2. The 3 or 4-digit abbreviations on the top right corner of the 18 Screens (Pages 1 to 19) for
“CHARGING”Mode(Column4,Group3)willindicateoneofthefollowing6chargingstates:
Abbreviation
Normal (N)
3 Stage Charging
Equalization
(E) 4-Stage Charging
N-CC Constant Current (CC),
Bulk Stage
–
N-CV Constant Voltage (CV),
Absorption Stage
–
E-CC
–
Constant Current (CC),
Bulk Stage
E-CVA
–
Constant Voltage Absorption
(CVA) Stage
E-CVE
–
Constant Voltage Equalization
(CVE) Stage
FLOAT Float Stage Float Stage
19Screens(Pages1to19)for“CHARGING”Mode(Column4,Group3)areshownasan
example for Bulk Charging Stage in Normal Charging Mode (N-CC). Depending upon the
Charging Mode and Stage the unit is in at any particular time, 19 sets of screens will be seen for
each of the 6 states of operation in Charging Mode: N-CC, N-CV, E-CC, E-CVA, E-CVE or Float
* Page Up is shown with downward pointer  because Page Nos. in this Menu Map increase in
the downward direction
** Page Down is shown with upward pointer  because Page Nos. in this Parameter Setting
Menu Map decrease in the upward direction
