90 | SAMLEX AMERICA INC.
Models EVO-2212 EVO-3012 EVO-2224 EVO-4024
INVERTER SECTION
Output Waveform Pure Sine Wave
Input Battery Voltage Range 9.1 - 17 VDC 18.1 - 34 VDC
Nominal AC Output Voltage 120 VAC ± 5%
Output Frequency 60 Hz ± 0.1 Hz
Total Harmonic Distortion of Pure
Sine Wave Form (THD)
< 5%
Continuous Output Power 2200 VA 3000 VA 2200 VA 4000 VA
Continuous AC Output Current 18A 25A 18A 33A
Surge Power for 1 msec
300%
(6600 VA, 54A)
300%
(9000VA, 75A)
300%
(6600VA, 54A)
300%
(12,000 VA, 99A)
Surge Power for 100 msec
200%
(4400VA, 36A)
200%
(6000VA, 50A)
200%
(4400VA, 36A)
200%
(8000VA, 66A)
Power Boost for 5 sec
150%
(3300W)
150%
(4500W)
150%
(3300W)
150%
(6000W)
Power Boost for 30 sec
140%
(3080W)
140%
(4200W)
140%
(3080W)
140%
(5600W)
Power Boost for 5 min
120%
(2640W)
120%
(3600W)
120%
(2640W)
120%
(4800W)
Power Boost for 30 min
110%
(2420W)
110%
(3300W)
110%
(2420W)
110%
(4400W)
Maximum Continuous DC Input
Current
266 A 373 A 133 A 266 A
Inverter Efciency (Peak)
90% 90% 93% 94%
No Load Power Consumption in
Power Saving Mode
< 8 W
No Load Power Consumption in
Normal Mode
(120 VAC Output, Typical)
30 watts 25 watts
AC INPUT FROM GRID / GENERATOR
AC Input Voltage 120VAC (60-140VAC +/- 5%)
AC Input Frequency 60Hz / 50Hz
Maximum Programmable (Default)
AC Input Current
5-40A
(Default 30A)
5-70A
(Default 30A)
5-40A
(Default 30A)
5-70A
(Default 30A)
TRANSFER CHARACTERISTICS
Transfer Relay Type and Capacity SPDT, 40A
DPDT, 70A
(2X35A contacts
in parallel)
SPDT, 40A
DPDT, 70A
(2X35A contacts
in parallel)
Transfer Time – Inverter to Grid /
Generator
< 1 ms (Synchronized Transfer at Zero Crossing)
Transfer Time – Grid / Generator
to Inverter
Up to 16ms (Synchronized Transfer)
SECTION 7 | Specications
