90 | SAMLEX AMERICA INC. SAMLEX AMERICA INC. | 91
Models EVO-2212 EVO-3012 EVO-2224 EVO-4024
OPERATING MODES
OFF-LINE Mode
Grid/Generator Priority (Default)
• Grid/Generator supplies AC loads and charges batteries
• Inverter is standby
ON-LINE Mode
Battery / Inverter Priority (Programmable)
• Inverter supplies AC loads even if Grid/Generator is available
• Grid/Generator takes over when batteries are discharged to "Battery
Low Alarm" to charge batteries and to power AC loads. AC loads are
transferred back to Inverter under various programmed conditions
INTERNAL BATTERY CHARGER SECTION
AC Input Voltage Range
120 VAC (60 to 140 VAC +/-5% )
Max Continuous AC Input Current 15A, AC 20A, AC 19A, AC 30A, AC
AC Input Power Factor
> 0.95
Programmable DC Output Charg-
ing Current
0-100A, DC 0 - 130A, DC 0 - 70A, DC 0 - 110A, DC
Charger Efciency 75% 86% 85%
Charging Stages
 Normal Mode: 3 Stages – Bulk, Absorption and Float
 Equalization Mode: 4 Stages – Bulk, Absorption, Equalization and Float
 Adaptive Charging Control
Battery Temperature Compensa-
tion
 Battery Temperature Sensor included
 Compensation Range from -20° C to 60° C
EXTERNAL BATTERY CHARGER SECTION (Solar Charge Controller)
Charging Voltage Range 13-15VDC 13-15VDC 26-30VDC 26-30VDC
Maximum Charging Current 50A
COOLING, PROTECTIONS AND ALARMS
Cooling
2 Fans – Temperature Controlled, Variable Speed
Protections and Alarms
Battery Low Voltage Alarm and Low / Over Voltage Shut Down
Shut Down under Input Over Current, Output Over Current, Output Over-
load and Output Short
Transformer and Heat Sink Overheat Shut Down
Immunity Against Conducted Electrical Transients in Vehicles
OPTIONAL REMOTE CONTROL
Model No.
EVO-RC (see Appendix A)
Specications
 Advanced Features for programming various parameters and modes of
operation
 2 Rows of 16 Character Alpha Numeric LCD Display for messaging
 Up to 16 GB SD Card Slot for Data Logging
 Comes with 10M / 33ft RJ-45 Data Cable
SECTION 7 | Specications
