TABLE 6.1 LED & BUZZER INDICATIONS FOR OPERATION MONITORING
Status Green LED "Status" Red LED "Fault" Buzzer
Seen during Power-On
Sequence
Indicates completion
of Power-On Sequence
after Power ON/OFF
Button is pressed for
2 sec
Flash 3 times OFF OFF
Seen during Power-Off
Sequence
Indicates comple-
tion of Power-Off
Sequence after Power
ON/OFF Button is
pressed for 5 sec
ON ON OFF
Normal charging Flash 1 time per second OFF OFF
Equalization charging Flash 2 times per second OFF OFF
Inverting ON OFF
Beep per 3 second
(Default OFF)
Low battery alarm ON Flash 1 time per second Beep per second
Power saving Flash 1 time per 3 second OFF OFF
Standby OFF OFF OFF
Fault OFF ON ON
NOTE:
Buzzer is available only in EVO Inverter Charger. There is no buzzer in Remote Control EVO-RC.
SECTION 6 | Monitoring of Operation
Using LED and Buzzer
