5.4 SAVING / UPLOADING PROGRAMMED PARAMETERS
5.4.1 Saving Programmed Parameters
All the programmed parameters can be saved on an SD Card (FAT 16 / FAT 32 Format, up to
16 GB capacity). The parameters will be saved in File named “xxxx_yyy.cfg”, where the rst
group of 4 digits xxxx is the Model No. e.g. 2212 or 2224 or 3012 or 4024 and the second
group of 3 digits YYY is the Revision No. for that Model e.g. 061.
• For saving, rst insert the SD Card in the SD Card Slot.
• Then, go to “Parameter Save” Screen (See Section 4.8 and Table 4.8 – under heading
"PARAMETER SAVE"). Steps are given below:
SELECT GROUP
CHARGE CURVE
SELECT GROUP
OTHER FUNCTION
PARAMETER SAVE
0 = No
POWER SAVING
1 = Enable
Up Key x 4
ò
Enter Key
ò
Up Key x 10
ò
• Now, select
PARAMETER SAVE
1 = Yes
Saved le end
PARAMETER SAVE
0 = No
. The parameters will be saved and message
PARAMETER SAVE
1 = Yes
Saved le end
PARAMETER SAVE
0 = No
will be seen and then, the screen will revert to
PARAMETER SAVE
1 = Yes
Saved le end
PARAMETER SAVE
0 = No
.
5.4.2 Uploading Saved Parameters
If there is a “xxxx_yyy.cfg” le in the SD card with stored programmed parameters, then on
inserting the card, the Remote Control will ask to upload the Cong File. Press Enter Button
to conrm or Back Button to cancel.
Upload conf?
Yes = Enter Key
Upload conf
1 %
Upload conf?
No = Back Key
Asks to conrm upload.
Upload conf?
Yes = Enter Key
Upload conf
1 %
Upload conf?
No = Back Key
Asks to cancel upload.
Upload conf?
Yes = Enter Key
Upload conf
1 %
Upload conf?
No = Back Key
Conguration uploading.
