SECTION 4 | Parameter Setup
alongperiodoftime,thebatterymaygetcompletelydischarged.Hence,atimerisused
to record the duration of “Battery low voltage!” condition. The EVO Inverter Charger will
be completely shut down (LCD Display / LED / Buzzer will be OFF) when the duration of the
“Battery low voltage!” fault condition as described above is equal to the “LV CUT OFF TIME”.
SELECT GROUP
CHARGE CURVE
BULK CURRENT
40 A
LV CUT OFF TIME
1200 sec
Enter Key
ò
Up Key x 10
ò
CHARGE MODE:
Default setting is 3-Stage "Normal Mode" (Parameter Screen setting shows "0=Normal").
The mode can be changed at any time to 4-stage "Equalization Mode" (Change Screen
setting to "1=Equalize"). After "Equalization Mode" is completed (the charger enters Float
Stage after completing Equalization Stage), the screen automatically resets to Normal (0=
Normal).
SELECT GROUP
CHARGE CURVE
BULK CURRENT
40 A
CHARGE MODE
0=Normal
Enter Key
ò
Up Key x 11
ò
ON-LINE / OFF-LINE UPS MODES
On-line UPS (Un-interruptible Power Supply) Mode:
i
INFO
The following programmable parameters have been referred to in the description
below. Links to detailed information on these parameters are given below:
 • “LOWVOLTALARM”:PleaserefertoPage8ofGroup1ofParameterSetup
Menu Map at Fig 4.1, Table 4.4 and Section 4.4
 • “GSDETECTTIME”:PleaserefertoPage16ofGroup1ofParameterSetup
Menu Map at Fig 4.1, Table 4.4 and Section 4.4
 • “ONLINEOPTIONS”:PleaserefertoPage14ofGroup1ofParameterSetup
Menu Map at Fig 4.1, Table 4.4 and Section 4.4
 • “CHARGEMODE”:PleaserefertoPage12ofGroup1ofParameterSetupMenu
Map at Fig 4.1, Table 4.4 and Section 4.4
 • “GENOFFTIME”:PleaserefertoPage18ofGroup1ofParameterSetupMenu
Map at Fig 4.1, Table 4.4 and Section 4.4
 • “RESETVOLTAGE”:PleaserefertoPage7ofGroup1ofParameterSetupMenu
Map at Fig 4.1, Table 4.4 and Section 4.4
On-line / Off-Line UPS Modes are programmed through Remote Control EVO-RC by setting
“ONLINE MODE” [1=ON]. The Default Setting is Off-Line Mode [0=OFF].
On-line UPS Mode is suitable for installations where both Grid and Photovoltaic (PV) Solar
Battery Charging System are available. It is also desirable in areas where Grid / Utility
energy rates are very high and use of supplementary battery based photovoltaic
power system is more cost effective. In this mode, un-interruptible AC power is provided
by utilizing batteries and the Inverter Section of EVO as the the PRIMARY DC-AC power
source. The Grid is the secondary / back-up AC power source. Even if qualied Grid AC input
