36 | SAMLEX AMERICA INC.
APPENDIX A
“NO” contacts of the Status Relay will open to initiate automatic stopping of the
Generator. When AC output from the Generator switches OFF, EVO will change over to
“Inverting Mode” (NOTE: The State of Charge of the battery after the Status Relay has
been switched OFF (de-energized) and Generator is stopped will be indeterminate).
Diagram showing steps for programming the above RELAY FUNCTION is given below:
SELECT GROUP
CHARGE CURVE
SELECT GROUP
OTHER FUNCTION
RELAY FUNCTION
2 = Generator 0
POWER SAVING
1 = Enable
Up Key x 4
ò
Enter Key
ò
Up Key x 4
ò
COMM ID:
Communication ID- This sets the ID number for the COMM Port and EVO-RC Remote Control.
SELECT GROUP
CHARGE CURVE
SELECT GROUP
OTHER FUNCTION
COMM. ID
1
POWER SAVING
1 = Enable
Up Key x 4
ò
Enter Key
ò
Up Key x 5
ò
BUZZER:
Set the buzzer ON/OFF.
SELECT GROUP
CHARGE CURVE
SELECT GROUP
OTHER FUNCTION
BUZZER
1 = ON
POWER SAVING
1 = Enable
Up Key x 4
ò
Enter Key
ò
Up Key x 6
ò
DISCHARGE BEEP:
To select the buzzer ON/OFF while in "Inverting Mode".
SELECT GROUP
CHARGE CURVE
SELECT GROUP
OTHER FUNCTION
DISCHARGE BEEP
0 = OFF
POWER SAVING
1 = Enable
Up Key x 4
ò
Enter Key
ò
Up Key x 7
ò
DEFAULT RESET
This is to reset all of the parameters to the Default Values.
SELECT GROUP
CHARGE CURVE
SELECT GROUP
OTHER FUNCTION
DEFAULT RESET
0 = No
POWER SAVING
1 = Enable
Up Key x 4
ò
Enter Key
ò
Up Key x 8
ò
DATALOG TIME AND DATALOG DISABLE:
Set the time period of the data log.
0 = Disable 1 = 1 sec 2 = 10 sec 3 = 30 sec
4 = 60 sec 5 = 5 min 6 = 10 min
SELECT GROUP
CHARGE CURVE
SELECT GROUP
OTHER FUNCTION
DATALOG TIME
1 = 1 sec
POWER SAVING
1 = Enable
Up Key x 4
ò
Enter Key
ò
Up Key x 9
ò
SECTION 4 | Parameter Setup
