Markings on the device
2 Markings on the device
2.1 Nameplate for Type2488N Valve
Nameplate for Type2488N Valve
1 Model number and conguration
ID
2 Order number or year of
manufacture
3 Type designation
4 Flow rate set point range in m³/h
5 Differential pressure at the
restriction in bar
6 Max. perm. differential pressure
Δp in bar
7 Flow coefcient K
VS
8 Max. permissible temperature in °C
9 Nominal pressure PN
1 2
3 4
5 6
7 8 9
Nameplate of Type5857 Actuator
1 Conguration ID
2 Serial number
3 Thrust
4 Rated travel
5 Transit time for rated travel
6 Power supply
7 Rated frequency
8 Power consumption
9 Input signal
10 Firmware version
Made in Germany
754
6
8
SAMSON 5857
Electric Actuator
s: t: f:U: P
:
Var.-ID
Serial-No.
1
2
F: 3
Made in Germany
94
6
8
SAMSON 5857
Electric Actuator
with digital positioner
s: In: U: P
:
Var.-ID
Serial-No.
1
Firmware-Version: 10
2
F: 3
Three-step version
Version with digital positioner
Fig.1: Nameplates for Type2488N Valve and Type5857 Actuator
