EB 8222-1 EN 5-3
Installation
Î When the valve and actuator are al-
ready assembled, check the tightening
torques of the bolted joints (uAB0100).
Components may loosen during trans-
port.
LegendforFig.5-1andFig.5-2
1 Support shaft
2 Yoke
3 Bottom ange
4 Insulating section
5 Valve body
7 Segmented ball
10 Spring
12 Valve shaft
15 Packing gland
17 Bearing bushing
18 Bearing bushing
30 Retainer
35 Bushing
40 V-ring packing
46 Gasket
49 Spacer
70 Retaining screw
80 Washer
88 O-ring seal
90 Gasket
